AWA Hydraulic Hammer S40/240 - G680 3-7T

AWA Hydraulic Hammer S40/240 - G680 3-7T

SKU A-RB-00003
70,343.00 kr - 70,343.00 kr
70,343.00 kr
70,343.00 kr - 70,343.00 kr
70,343.00 kr

AWA Hydraulic Hammer S40/240 G680

Controlled breaking performance for 3–7T excavators

The AWA Hydraulic Hammer S40/240 G680 is designed to deliver dependable, controlled breaking power for 3–7 tonne carriers. Built around smart energy transfer and reduced vibration, it helps operators work efficiently across a wide range of demolition and site preparation tasks while protecting the machine.

With a 325 kg operating weight, 40–70 L/min oil flow, 110–140 bar working pressure, and 500–900 blows per minute, the G680 is tuned for steady, consistent performance without unnecessary stress on hydraulics or components.

Manufactured from high-quality alloy steel and featuring a sealed lubrication system, the hammer supports long service life and reduced maintenance. Extensive real-world testing ensures reliable operation in demanding conditions.

Delivering professional-grade performance at excellent value, the S40/240 G680 is a smart choice for contractors who need capability, control, and reliability — without overpaying.

Controlled power. Smart design. Real value.

AWA — Smart. Reliable. Accessible.
That’s how you Drive the Unstoppable.

Read More

Reinforced tool bushings and welded design maximize energy transfer—68 mm chisel pierces concrete and rock with surgical accuracy.

Vibration-Taming Engineering

Advanced damping absorbs shocks, protecting your carrier and crew; 1/2 inch hoses for seamless, leak-free flow.

Scalable Demolition Dominance

S40 hitch for 3-7 ton excavators—seamless integration, endless endurance in the toughest breakdowns.

Australian Toughness. Swedish Engineering.

Specifications

Hydraulic Hammer S40/240 – G680 details:

  • Body weight: 325 kg
  • Working Flow Rate: 40-70 L/min
  • Working pressure (bar): 110-140
  • Impact rate (bpm): 500-900
  • Hose diameter (inch): 1/2
  • Chisel diameter (mm):68

Hydraulic Hammer S40/240 – 680 is designed for:

  • Excavator weight 3-7 tons
  • S-series hitch S40/240
